DIN Rail Mini Circuit Breaker

  • MCB WSB1-80
  • MCB WSB1-80
  • MCB WSB1-80
  • MCB WSB1-80
  • MCB WSB1-80
  • MCB WSB1-80
MCB WSB1-80 MCB WSB1-80 MCB WSB1-80 MCB WSB1-80 MCB WSB1-80 MCB WSB1-80

MCB WSB1-80

  • Product ID: Miniature Circuit Breaker WSB1-80(H)
  • size: 6kA, 10kA
  • INQUIRY

Key Information

WSB1-80

Pole: 1, 2, 3, 4

Voltage: AC230V/400V

kA: 6kA, 10kA

Amps: 6, 10, 16, 20, 25, 32, 40, 50, 63, 80

Width: 18, 36, 54, 72mm

General

WSB1-80 series Miniature Circuit Breaker is mainly applied at lines of AC 50Hz or 60Hz, rated operation voltage AC230V/400V, rated current upto 80A, for overloading and short circuit protection to the circuit, also for changeover of infrequent operation to the circuit. The MCB is used at places of commercial office building, residential building and buildings similar.

The product meets standards of IEC/EN60898-1 and GB10963.1, at advanced international quality level.

Main technical parameters

  1. No.

Rated currentInitial stateTest currentTime limitExpected result
1In≤63Cold state1.13Int≤1hNot tripping
In>63t≤2h
2In≤63Just followed the last test item1.45Int<1hTripping
In>63t<2h
3In≤32Cold state2.55In1sTripping
In>321s
4Type CCold state5Int≤0.1sNot tripping
10Int<0.1sTripping
